Jaeger LeCoultre list of all calibers and explanation of their structure

May 30, 2025

Caliber designations (Source: Uhren Wiki / Stephen Foskett)

Jaeger-LeCoultre uses numbers to identify its calibers. There is a rough system for numbering, with smaller calibers receiving lower numbers and larger and more expensive calibers receiving higher numbers. Jaeger-LeCoultre also tends to use similar numbers for related calibers, although this is not always the case. In most cases, variants of a base caliber of the same generation receive numbers from the same decade, while major revisions receive a new decade. For example, caliber 889 was replaced by caliber 899, and variants of the latter included calibers 896 and 898.

The prefix letters generally refer to shock-absorbing systems, although these are rarely used today. "P" stood for Parachoc , while "K" stood for Kif .

Numerical suffixes indicate minor revisions, as is the case with other movement manufacturers. For example, some Jaeger-LeCoultre calibers have a "/2" variant when changes were made that did not require a new caliber number.

Suffixes indicate complications or features: "SQ" stands for a skeleton ("squelette"), while other letters often denote complications, certifications, or applications. The Caliber K880G, for example, was a chronometer-certified version of the Caliber 880 with Kif shock protection.

Manual winding

Tonneau
- 101 , 104 , 403 , 406 - 2×6.25 lines “Duoplan”
- 202 , 207 - 19 or 22 lines (similar to 201 / 206 )
- 404, 407 - Lady Reverso original
- 410, 11LO, 413, 424, 438 , 411, 437 , 412, 436, 486, 806 - 8×11 lines Reverso
- 460, 490, 491 - Reverso oval
- 807, 840, 845 - 5.75×7 line tonneau
- 822 , 823 , 843 , 844 , 846 , 851 , 854 , 864 , 865 - Reverso modern
- 976 , 986 - Reverso 28,800 Autotractor
- 873 , 874 , 875 , 878 , 879 - Reverso 8 days
Around
- 117 , 122 , 408 - 9 lines
- 139 - 16 lines
- 140 , 145 , 415 - 17 lines
- 168 - 8/9 lines
- 169 , 426 - 7 lines
- 201 , 205 , JLC 206 , 208 - 19 or 22 lines (similar to 202 / 207 )
- 380 , 381 , 383 - Duometer
- 449, 452, 463, 469, 479 , 451, 464, 484 , 494 - 12.75 lines sub-seconds
- 450, 468 - 12.75 lines central second
- 470, 478, 488 - 12.75 lines chronometer
- 480, 483 - 10.5 lines small second
- 800, 810 - 10.5 lines central second
- 818, 819 - 9.25 lines narrow
- 838/839 , 849 - Ultra-slim
- 876 , 877 - 8 Days

$Kaliber JLC 489\\ © [[Jaeger-LeCoultre]] (zum Vergrößern anklicken!)$
Caliber JLC 489
© Jaeger-LeCoultre

alarm
- 489/601 , 814 , 910/911 , 914 - Memovox alarm

Automatic

Around
- 476 , 481 , 813 - hammer automatic
- 497, 817, 827, 837 - Futurematic
- 809 - Rendezvous Celestial
- 880, 881, 882, 883, 885 - 11.5 lines Geomatic
- 889 , 896 , 897 , 898C , 899 - Ultra slim
  - 929 , 923 , 936 , 937 , 939 - Complications in ultra-thin
- 891 , 924 , 866 , 868 - Master calendar
- 920 - Ultra-slim OEM (not used by JLC)
- 925 - Flat with moon phase and date
- 928 , 938 - Master Reserve de Marche
- 939 - Master Geographic
- 967 - Compact
- 960 - Master Compressor Automatic
- 966 , 968 - Reverso Squadra Lady Duetto
- 970 , 971 , 972 , 975 , 977 , 979 - "Autotractor" - Unidirectional, robust, ceramic bearings
